WIRELESSStandardsWi-Fi 4
IEEE 802.11n/b/g 2.4 GHzWiFi SpeedsN300
2.4 GHz: 300 Mbps (802.11n)WiFi Range2 Bedroom Houses

2× Fixed AntennasWiFi CapacityLegacyWorking ModesRouter Mode
Access Point Mode
Range Extender Mode
WISP ModeHARDWAREProcessorSingle-Core CPUEthernet Ports1× 10/100 Mbps WAN Port
4× 10/100 Mbps LAN PortsButtonsReset ButtonPower5 V - 0.6 ASECURITYWiFi EncryptionWEP
WPA
WPA2
WPA/WPA2-Enterprise (802.1x)Network SecuritySPI Firewall
Access Control
IP & MAC Binding
Application Layer GatewayGuest Network1× 2.4 GHz Guest NetworkSOFTWAREProtocolsIPv4
IPv6Parental ControlsURL Filtering
Time ControlsWAN TypesDynamic IP
Static IP
PPPoE
PPTP
L2TPQuality of ServiceQoS by DeviceNAT ForwardingPort Forwarding
Port Triggering
DMZ
UPnPIPTVIGMP Proxy
IGMP Snooping
Bridge
Tag VLANDHCPAddress Reservation
DHCP Client List
ServerDDNSNO-IP
DynDNSManagementTether App
Webpage
PHYSICALDimensions (W×D×H)4.5 × 4.2 × 1.0 in
(115 × 106.7 × 24.3 mm)Package ContentsWi-Fi Router TL-WR844N
Power Adapter
RJ45 Ethernet Cable
Quick Installation GuideOTHERSSystem RequirementsInternet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

Cable or DSL Modem (if needed)

Subscription with an internet service provider (for internet access)CertificationsFCC, CE, RoHSEnvironmentOperating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensingTEST DATAWiFi Transmission PowerCE:
<20dBm(2.4GHz)
FCC:
<30dBmWiFi Reception Sensitivity270M: -70dBm@10% PER
130M: -74dBm@10% PER
108M: -74dBm@10% PER
54M: -77dBm@10% PER
11M: -87dBm@8% PER
6M: -90dBm@10% PER
1M: -98dBm@8% PER
